Type: Colinear
- Frequency range @ SWR ≤1.5:
- Impedance: 50Ω
- Radiation (H-plane): 360° omnidirectional
- Radiation (E-plane): beamwidth @ -3 dB = 40°
- Radiation angle: 0°
- Polarization: linear vertical
- Gain: 3 dBd - 5.15 dBi
- Max. power (CW) @ 30°C: 75 Watts
- Grounding protection: All metal part are DC-grounded, the inner conductor shows a DC-short
- Connector: N-female with rubber protection cap

MECHANICAL DATA:
- Materials: White fiberglass radome Ø 28.6mm, anodized 6063-t5 aluminium, brass, stainless steel, copper, EPDM rubber
- Wind load / resistance: 53 N @ 150 Km/h / 150 Km/h
- Wind surface: 0.044 m²
- Height (approx.): 1380 mm
- Weight (approx.): 1200 gr
- Operating temperature: -40°C to +80°C
- Mounting mast: Ø 35-54 mm

PRICE €179
